Product Specifications
| Feature | Details |
|---|---|
| Device Type | 12-lead Electrocardiograph with thermal printing system |
| Display Modes | 3/6/12-lead ECG display, includes DEMO mode |
| Printing System | High-resolution thermal printing (8 dots/mm), up to 150Hz recording frequency |
| Filters | Full-digital design with baseline drift, AC, and EMG interference filters |
| Measurement Modes | Auto, manual, and rhythm recording |
| ECG Waveform Management | Real-time, continuous recording with annotations (lead mark, sensitivity, paper speed, filter state) |
| Lead Acquisition | Sync collection for 12-lead ECG, multiple printing formats |
| Data Storage | Stores over 1,000 cases with case database management |
| Print Settings | Options for “Print and save,” “Print no save,” and “Save no print” |
| Language Options | Multi-language support (Chinese, English, French, Spanish, Turkish, etc.) |
| Power Source | Built-in rechargeable lithium battery (AC/DC), auto power-off after inactivity |
| Time Printing | Adjustable intervals: 1/2/3/5/10/20/30/60 minutes |
Performance Specifications
| Parameter | Specification |
|---|---|
| Input Mode | Floating and defibrillation protection |
| Frequency Response | 0.05Hz to 150Hz (-3dB ~ +0.4dB) |
| CMRR | >60dB; >100dB with filter |
| Time Constant | ≥3.2 seconds |
| Noise Level | <15µVp-p |
| Calibration Voltage | 1mV |
| Sampling Frequency | 1,000Hz |
| Measurement Parameters | HR, P-R interval, QRS Duration, T Duration, Q-T interval, Q-Tc, P/QRS/T Axis, etc. |
| Paper Size | 80mm (W) × 20m (L) |
| Paper Speed | 5, 6.25, 10, 12.5, 25, 50, 100 mm/s |
| Safety Classification | Class I, Type CF, defibrillation-proof applied part |
Physical Characteristics
| Specification | Details |
|---|---|
| Dimensions | 315mm (L) × 215mm (W) × 92mm (H) |
