Accu-Check AC-550 Wrist-Type Digital Blood Pressure Monitor

Product Specifications

Main Specifications:

• Name: Electronic Blood Pressure Monitor
• Model: AC-550
• Display Mode: Digital display
• Measurement Mode: Oscillometry method
• Wrist Perimeter Measurement: 135-215 mm

Environmental Specifications:

• Usage Temperature and Humidity: +5 to 40°C, 15%-85% RH
• Transportation and Preservation Temperature: -20 to +60°C
• Transportation and Preservation Atmospheric Pressure: 500-1060 hPa

Performance:

• Accuracy:
  • Pressure: ±3 mmHg (within ±4 kPa)
  • Pulse Rate: Accuracy ±5%
• Measurement Range:
  • Pressure: 0-299 mmHg (0-39.9 kPa)
  • Pulse Rate: 40-180 times/min.

Power and Dimensions:

• Power: Two 7-type batteries
• Battery Life: Approximately 300 measurements under the conditions of a 7# alkaline battery, 23°C temperature, arm perimeter of 25 cm, and 170 mmHg (22.7 kPa) pressure
• Weight: Approximately 110 g (including battery weight)
• Dimensions: Length 78.5 mm x Width 68.5 mm x Height 30 mm (including preservation strips and cuff)

Additional Information:

• Run Atmospheric Pressure: 700-1060 hPa
• Attachments: Packing box, product specification, certificate of inspection
