LifeCare Medical LC-ECG3200 ECG Machine

Description

Specifications

• 7-inch high resolution color touch screen
• 12-lead simultaneous acquisition and display
• ECG automatic measurement and interpretation function
• Complete digital filters for resisting:
  • baseline drift
  • AC interference
  • EMG interference
• Compact and lightweight design
• Supports USB flash disk and micro SD card to extend memory
• Software upgrade via USB / SD card
• Built-in rechargeable Li-ion battery

Standard Configuration

• Main machine: 1 PC
• Patient cable: 1 PC
• Limb electrode: 1 set (4 pcs)
• Chest electrode: 1 set (6 pcs)
• Power cable: 1 PC
• 80mm × 20M recording paper: 1 PC
• Paper axis: 1 PC
• Power cord: 1 PC

The LC-ECG3200 Electrocardiograph is a compact and lightweight 12-lead ECG machine with a 7-inch high-resolution color touch screen, automatic ECG measurement and interpretation, thermal printing, USB/SD storage support, and a built-in rechargeable lithium battery. It is suitable for hospitals, clinics, and diagnostic centers.

Key Specifications

• Display: 7-inch high resolution color touch screen
• Leads: Standard 12 leads
• Acquisition: Simultaneous 12-lead acquisition
• Measurement Range: ±5mVpp
• Input Impedance: ≥50MΩ
• Frequency Response: 0.05Hz ~ 150Hz
• Sensitivity: 2.5 / 5 / 10 / 20 mm/mV
• Paper Speed: 12.5 / 25 / 50 mm/s
• Recording Method: Thermal printing
• Paper Size: 80mm × 20M
• Storage Expansion: USB flash disk / micro SD card
• Battery: Built-in rechargeable Li-ion battery
• Power Supply: AC 100–240V, 50/60Hz; DC 14.8V / 2200mAh
• Sample Rate: 1000 sps/channel
• Safety Standard: IEC I/CF
