Heartlines H12 12-Lead, 12-Channel ECG Machine

Description

Key Features

These map to how buyers search; lead with the benefit, keep the keyword.

• 12-Lead Simultaneous Acquisition — captures all 12 leads at once and displays a full-screen 12-channel ECG waveform for faster, more accurate readings.
• Automatic ECG Interpretation — built-in auto-analysis and auto-diagnosis reduce physician workload and improve clinical efficiency.
• 7″ Color Touch Screen — operate via touch or push-button, with on-screen waveform freezing and review.
• High-Resolution Thermal Printer — 216 mm thermal paper with synchronized printing and an 8 dots/mm thermal array; no manual adjustment needed.
• Smart Signal Filtering — ADS (baseline drift), HUM (AC interference) and EMG (muscle) filters with automatic baseline adjustment for clean recordings.
• 400+ ECG Internal Storage — review, recall and reprint historical records and patient data from built-in flash memory.
• Pacemaker Detection & Lead-Off Alarm — added safety and reliability during acquisition.
• Portable & Rechargeable — built-in li-ion battery with AC/DC operation; works on 100–240V, 50/60Hz. Lightweight at 3.5 kg.
• Wide Frequency Response (up to 150 Hz) — for diagnostic-grade signal fidelity.
• RS232 & USB Connectivity — easy data transfer and PC integration.

Long Description

The Heartlines H12 12-channel ECG machine with interpretation is a compact, diagnostic-grade electrocardiograph designed for clinics, hospitals and diagnostic labs. It simultaneously acquires all 12 ECG leads and displays a full-screen 12-channel waveform on a responsive 7-inch color touch screen, giving clinicians a clear, real-time view of cardiac activity.

Powered by automatic measurement, calculation and auto-interpretation, the H12 generates analysis results — heart rate, PR, QRS, QT/QTc intervals and more — that help reduce diagnostic time and physician burden (results to be confirmed by a doctor). Intelligent ADS, HUM and EMG filters with automatic baseline correction ensure clean, artifact-free tracings.

The integrated high-resolution thermal printer uses 216 mm paper with an 8 dots/mm thermal array for crisp, synchronized 12-channel printouts. With storage for 400+ ECG records, plus pacemaker detection, lead-off alarm and waveform freezing, the H12 combines clinical reliability with everyday convenience.

A built-in rechargeable li-ion battery and universal AC/DC power (100–240V, 50/60Hz) make it suitable for both bedside and portable use, while USB and RS232 interfaces simplify data export. At just 3.5 kg, the Heartlines H12 delivers a quality, economical and durable ECG solution.
